功能特点

• 更优异的性能:更大的气量输出；高性能IP55 电机（低压）；全系列定/ 变速驱动
• 更低安装和维护成本：单点电源连接；长寿命消耗件；全新门把手及门锁功能；出厂预装8000小时全合成冷却剂
• 高可靠性：超级涂层机械结合涂层；V-Shield™科技；所有密封元件均无硅

• 适应不同应用的选项：高效集成水分后冷选项；无损排污；高粉尘过滤

  技术参数

• I-Fixed speed

•

• Model	Rated pressure barg	Rated power kW	Gas displacement (FAD) m³/min	Dimensions (L×W×H) mm	Weight kg
  LS200i_W2.75 G03	2.75	200	56.6	4100X2150X2470	6320
  LS200i_W3.0 G04	3.0	200	49.6	4100X2150X2470	6320
  LS200i_W3.25 G04	3.25	200	49.1	4100X2150X2470	6320
  LS250i_W2.75 G01	2.75	250	68.6	4100X2150X2470	6760
  LS250i_W3.0 G03	3.0	250	56.3	4100X2150X2470	6760
  LS250i_W3.0 G02	3.0	250	62	4100X2150X2470	6760
  LS250i_W3.25 G02	3.25	250	61.5	4100X2150X2470	6760
  LS250i_W3.5 G04	3.5	250	48.8	4100X2150X2470	6760
  LS250i_W3.5 G03	3.5	250	55.5	4100X2150X2470	6760
  LS315i_W3.0 G01	3.0	315	68.3	4100X2150X2470	6760
  LS315i_W3.0 GO5	3.0	315	75.3	4100X2150X2470	6760
  LS315i_W3.0 G06	3.0	315	82.3	4100X2150X2470	6760
  LS315i_W3.25 G05	3.25	315	74.8	4100X2150X2470	6760
  LS315i_W3.5 G02	3.5	315	61.2	4100X2150X2470	6760
  LS315i_W3.5 G01	3.5	315	67.5	4100X2150X2470	6760
  LS355i_W3.5 G05	3.5	355	74.6	4100X2150X2470	6990
  LS355i_W3.5 G07	3.5	355	78.5	4100X2150X2470	6990
  LS200i_A2.75 G03	2.75	200	56.6	4100X2150X2470	6480
  LS200i_A3.0 G04	3.0	200	49.6	4100X2150X2470	6480
  LS250i_A2.75 G01	2.75	250	68.6	4100X2150X2470	6920
  LS250i_A3.0 G04	3.0	250	56.3	4100X2150X2470	6920
  LS250i_A3.0 G02	3.0	250	62	4100X2150X2470	6920
  LS315i_A3.0 G01	3.0	315	68.3	4100X2150X2470	6920
  LS315i_A3.0 G05	3.0	315	75.3	4100X2150X2470	6920
  LS315i_A3.0 G06	3.0	315	82.3	4100X2150X2470	6920

•

• N-variable speed

•

• Model	Rated pressure barg	Rated power kW	Gas displacement (FAD) m³/min	Dimensions (L x Wx H) mm	Weight kg
  LS200n_W2.75	2.5-2.75	200	61.1	4100X2150X2470	6650
  LS200n_W3.5	2.5-3.5	200	61.1	4100X2150X2470	6650
  LS250n_W3.0	2.5-3.0	250	69.2	4100X2150X2470	6660
  LS250n_W3.5	2.5-3.5	250	69.2	4100X2150X2470	6660
  LS315n_W3.0	2.5-3.0	315	82.9	4100X2150X2470	6860
  LS315n_W3.5	2.5-3.5	315	79.6	4100X2150X2470	6860
  LS355n_W3.5	2.5-3.5	355	79.6	4100X2150X2470	6990
  LS200n_A2.75	2.5-2.75	200	61.1	4100X2150X2470	6810
  LS250n_A3.0	2.5-3.0	250	69.2	4100X2150X2470	6820
  LS315n_A3.0	2.5-3.0	315	82.9	4100X2150X2470	7020

•
